Dimension drawings
A.7 Dimension drawing of system power supply, 70 mm wide
S7-1500 Automation System
System Manual, 01/2013, A5E03461182-01
185
Figure A-17 Dimension drawing of system power supply (70 mm wide), side view with open front
cover
Note
Minimum clearances
Observe the minimum clearances of 25 mm, above and below the mounting rail, as
described in the chapterMounting (Page 39).
