Siemens SIMATIC S7-1500 Automation System User Manual

Technical specifications
15.4 Mechanical and climatic ambient conditions
S7-1500 Automation System
System Manual, 01/2013, A5E03461182-01
171
15.4 Mechanical and climatic ambient conditions
Operating conditions
The S7-1500 automation system is suitable for use in weather-proof, fixed locations. The
operating conditions exceed requirements according to DIN IEC 60721-3-3:
● Class 3M3 (mechanical requirements)
● Class 3K3 (climatic requirements)
Test of mechanical ambient conditions
The table below provides important information with respect to the type and scope of the test
of ambient mechanical conditions.
Table 15- 8 Test of mechanical ambient conditions
Condition tested Test Standard Remark
Vibration Vibration test
according to
IEC 60068-2-6 (Sinus)
Type of oscillation: Frequency sweeps with a rate of change of 1
octave/minute.
5 Hz ≤ f ≤ 8.4 Hz, constant amplitude 7 mm
8.4 Hz ≤ f ≤ 150 Hz, constant acceleration 2 g
Duration of oscillation: 10 frequency sweeps per axis, along each of the
3 mutually perpendicular axes
Shock Shock, tested
according to
IEC 60068-2-27
Type of shock: Half-sine
Shock intensity: 15 g max., duration 11 ms
Direction of shock: 3 shocks each in (+/-) direction, along each of the
3 mutually perpendicular axes
Continuous shock Shock, tested
according to
IEC 60068-2-27
Type of shock: Half-sine
Shock intensity: 250 m/s
2
peak value, 6 ms duration
Direction of shock: 1000 shocks each in (+/-) direction, along each of the
3 mutually perpendicular axes
Reduction of vibrations
If your S7-1500 automation system is exposed to severe shock or vibration, take appropriate
measures to reduce the acceleration or the amplitude.
We recommend the installation of the S7-1500 automation system on damping materials
(for example, rubber-bonded-to-metal mounting).

Siemens SIMATIC S7-1500 Automation System Specifications

General

Series	SIMATIC S7-1500
Programming	TIA Portal (Totally Integrated Automation Portal)
Protection Class	IP20
CPU	Various models available (e.g., CPU 1511-1 PN, CPU 1518-4 PN/DP)
Controller Type	Modular Controller
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Communication Interfaces	PROFINET, PROFIBUS, Ethernet, OPC UA
Digital Inputs	Varies by model and expansion modules
Digital Outputs	Varies by model and expansion modules
Analog Inputs	Varies by model and expansion modules
Analog Outputs	Varies by model and expansion modules
Backplane Bus	High-speed backplane bus for fast communication between modules
Redundancy	Supported with specific models and configurations
Safety	Integrated safety functions available
Scalability	Highly scalable with modular expansion
Operating Temperature	0°C to 60°C
