Maintenance
9.4 Firmware update
S7-1500 Automation System
124 System Manual, 01/2013, A5E03461182-01
Special feature at a firmware update of analog modules
If you want to carry out a firmware update for analog modules, you have to supply 24 VDC
load supply to the module through the power supply element.
Procedure
1. Remove any inserted SIMATIC memory card.
2. Insert the SIMATIC memory card with the firmware update files into the CPU.
3. The firmware update begins shortly after the SIMATIC memory card has been plugged.
The display indicates that the CPU is in STOP mode, and that a firmware update is being
executed (STOP [FW UPDATE]). It displays the progress of the firmware update.
Possibly occurring errors during the firmware update will likewise be displayed on the
display.
4. After a completed firmware update, the display indicates that you can remove the
SIMATIC memory card.
The RUN LED of the CPU lights up yellow, the MAINT LED flashes yellow.
Note
If your hardware configuration contains several modules, to which a firmware update from
the SIMATIC memory card can be applied, then the CPU updates all affected module in the
slot sequence, i.e. in increasing sequence of the module position in the STEP 7 device
configuration.
Reference
Further information on the procedure can be found in the STEP 7 online help.

Siemens SIMATIC S7-1500 Automation System Specifications

General

Series	SIMATIC S7-1500
Programming	TIA Portal (Totally Integrated Automation Portal)
Protection Class	IP20
CPU	Various models available (e.g., CPU 1511-1 PN, CPU 1518-4 PN/DP)
Controller Type	Modular Controller
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Communication Interfaces	PROFINET, PROFIBUS, Ethernet, OPC UA
Digital Inputs	Varies by model and expansion modules
Digital Outputs	Varies by model and expansion modules
Analog Inputs	Varies by model and expansion modules
Analog Outputs	Varies by model and expansion modules
Backplane Bus	High-speed backplane bus for fast communication between modules
Redundancy	Supported with specific models and configurations
Safety	Integrated safety functions available
Scalability	Highly scalable with modular expansion
Operating Temperature	0°C to 60°C
