Product overview
2.1 What is the S7-1500 Automation System?
S7-1500 Automation System
14 System Manual, 01/2013, A5E03461182-01
Configuration example
The following figure shows a configuration example of an S7-1500 automation system.
① System power supply module
② CPU
③ I/O modules
④ Mounting rail with integrated top-hat rail profile
Figure 2-1 Example configuration of an S7-1500 automation system
