Siemens SIMATIC S7-1500 Automation System User Manual

Technical specifications
15.2 Electromagnetic compatibility
S7-1500 Automation System
System Manual, 01/2013, A5E03461182-01
169
Sinusoidal disturbances
The following table shows the electromagnetic compatibility of the S7-1500 automation
system with regard to sinusoidal disturbances (RF radiation).
Table 15- 3 Sinusoidal disturbances with RF radiation
RF radiation in accordance with IEC 61000-4-3/NAMUR 21
Electromagnetic RF field, amplitude-modulated
corresponds with degree
of severity
80 to 1000 MHz; 1.4 to 2 GHz 2.0 GHz to 2.7 GHz
10 V/m 1 V/m
80 % AM (1 kHz)
3
The following table shows the electromagnetic compatibility of the S7-1500 automation
system with regard to sinusoidal disturbances (RF coupling).
Table 15- 4 Sinusoidal disturbances with RF coupling
RF coupling in accordance with IEC 61000-4-6 corresponds with degree
of severity
from 10 kHz
10 V
rms
80 % AM (1 kHz)
150 Ω source impedance
3
Emission of radio interference
Interference emission of electromagnetic fields in accordance with EN 55016: Limit value
class A, group 1 (measured at a distance of 10 m).
Table 15- 5 Interference emission of electromagnetic fields
Frequency Interference emission
30 MHz to 230 MHz < 40 dB (µV/m) QP
230 MHz to 1000 MHz < 47 dB (µV/m) QP
Table 15- 6 Interference emission via the AC power supply
Frequency Interference emission
0.15 MHz to 0.5 MHz < 79 dB (µV/m)Q
< 66 dB (µV/m) M
0.5 MHz to 30 MHz < 73 dB (µV/m)Q
< 60 dB (µV/m) M
Interference emission via the AC power supply in accordance with EN 55016: Limit value
class A, Group 1.

Siemens SIMATIC S7-1500 Automation System Specifications

General

Series	SIMATIC S7-1500
Programming	TIA Portal (Totally Integrated Automation Portal)
Protection Class	IP20
CPU	Various models available (e.g., CPU 1511-1 PN, CPU 1518-4 PN/DP)
Controller Type	Modular Controller
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Communication Interfaces	PROFINET, PROFIBUS, Ethernet, OPC UA
Digital Inputs	Varies by model and expansion modules
Digital Outputs	Varies by model and expansion modules
Analog Inputs	Varies by model and expansion modules
Analog Outputs	Varies by model and expansion modules
Backplane Bus	High-speed backplane bus for fast communication between modules
Redundancy	Supported with specific models and configurations
Safety	Integrated safety functions available
Scalability	Highly scalable with modular expansion
Operating Temperature	0°C to 60°C
