Siemens SIMATIC S7-1500 Automation System User Manual

Product overview
2.3 Properties
S7-1500 Automation System
System Manual, 01/2013, A5E03461182-01
19
Properties of the connection technology
Table 2- 3 Properties of the connection technology
Properties of the connection technology Explanation
Twistable front connector
• Rapid module exchange during maintenance
(cable duct remains closed)
Pre-wiring position
• More user-friendly, because the module
wiring is easily accessible
• No loosening of the wiring when replacing a
module
• No electrical damage to the module is
possible, because it is not yet electrically
connected
Development of a potential group by the insertion
of potential bridges
• Reduced wiring effort on the front cable
connector
Integrated EMC concept (power supply element,
shielding bracket, and terminal element)
• Reduction of the interference emission and
optimization of the interference immunity
Consistent 40-pin front connector for all modules,
with a width of 35 mm
• Simplified ordering
Two snap-in positions of the front cover
• Flexible cable storage space
Automatic coding of the I/O modules and front
cable connectors
• Safe replacement of modules
Large label
• Sufficient space for clear identification and
user-specific labeling, e.g. symbolic
addresses

Siemens SIMATIC S7-1500 Automation System Specifications

General

Series	SIMATIC S7-1500
Programming	TIA Portal (Totally Integrated Automation Portal)
Protection Class	IP20
CPU	Various models available (e.g., CPU 1511-1 PN, CPU 1518-4 PN/DP)
Controller Type	Modular Controller
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Communication Interfaces	PROFINET, PROFIBUS, Ethernet, OPC UA
Digital Inputs	Varies by model and expansion modules
Digital Outputs	Varies by model and expansion modules
Analog Inputs	Varies by model and expansion modules
Analog Outputs	Varies by model and expansion modules
Backplane Bus	High-speed backplane bus for fast communication between modules
Redundancy	Supported with specific models and configurations
Safety	Integrated safety functions available
Scalability	Highly scalable with modular expansion
Operating Temperature	0°C to 60°C
