Installation
5.4 Mounting a load current supply module
S7-1500 Automation System
48 System Manual, 01/2013, A5E03461182-01
For a description on how to wire the power cable connector refer to the section Connecting
the system power supply and load current supply modules (Page 62).
Note
Load current supplies can be mounted to the left or right of the configured setup. If you
mount a load current supply on the right of the configured setup, the heat development of the
load current supply may make a gap to the configured setup necessary. For additional
information, refer to the relevant manuals. The number of load current supplies that can be
used is unlimited.
Dismantling the load current supply
The load current supply is wired up.
1. Turn off the fed supply voltage.
2. Open the front cover.
3. Shut down the load current supply.
4. Disconnect the power cable connector, and remove the connector from the load current
supply.
5. Undo the power supply module's fixing screw(s).
6. Swivel the load current supply out of the mounting rail.
Reference
Further information can be found in the Manuals for the load current supplies.

Siemens SIMATIC S7-1500 Automation System Specifications

General

Series	SIMATIC S7-1500
Programming	TIA Portal (Totally Integrated Automation Portal)
Protection Class	IP20
CPU	Various models available (e.g., CPU 1511-1 PN, CPU 1518-4 PN/DP)
Controller Type	Modular Controller
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Communication Interfaces	PROFINET, PROFIBUS, Ethernet, OPC UA
Digital Inputs	Varies by model and expansion modules
Digital Outputs	Varies by model and expansion modules
Analog Inputs	Varies by model and expansion modules
Analog Outputs	Varies by model and expansion modules
Backplane Bus	High-speed backplane bus for fast communication between modules
Redundancy	Supported with specific models and configurations
Safety	Integrated safety functions available
Scalability	Highly scalable with modular expansion
Operating Temperature	0°C to 60°C
