Wiring
6.1 Rules and regulations for operation
S7-1500 Automation System
54 System Manual, 01/2013, A5E03461182-01
24 VDC supply
The following describes what you must pay attention to in terms of the 24 VDC supply:
● Power supply units for the 24 VDC supply have to have a safe electrical isolation in
accordance with IEC 60364-4-41.
● Overvoltage arresters are to be used as protection against lightning and overvoltages.
Suitable components for the lightning and overvoltage protection are specified in the
Defining interference-free controllers
(http://support.automation.siemens.com
/WW/view/en/59193566) function manual.
Protection against electrical shock
The mounting rail of the S7-1500 automation system has to be connected conductively with
the protective conductor as protection against electrical shock.
Protection against external electrical influences
The following describes what you must pay attention to in terms of protection against
electrical influences and/or faults:
● For all plants or systems in which an S7-1500 CPU is integrated, you must ensure that
the plant or the system is connected to a protective conductor with sufficient cross-
section for conducting electromagnetic disturbances.
● For supply, signal and bus lines, you must ensure that the laying of the lines and the
installation is correct.
● For signal and bus lines, you must ensure that a wire/cable breakage or a cross-wire
does not lead to undefined states of the plant or system.
Reference
Additional information can be found in the function manual, Designing interference-free
controllers (http://support.automation.siemens.c
om/WW/view/en/59193566).

Siemens SIMATIC S7-1500 Automation System Specifications

General

Series	SIMATIC S7-1500
Programming	TIA Portal (Totally Integrated Automation Portal)
Protection Class	IP20
CPU	Various models available (e.g., CPU 1511-1 PN, CPU 1518-4 PN/DP)
Controller Type	Modular Controller
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Communication Interfaces	PROFINET, PROFIBUS, Ethernet, OPC UA
Digital Inputs	Varies by model and expansion modules
Digital Outputs	Varies by model and expansion modules
Analog Inputs	Varies by model and expansion modules
Analog Outputs	Varies by model and expansion modules
Backplane Bus	High-speed backplane bus for fast communication between modules
Redundancy	Supported with specific models and configurations
Safety	Integrated safety functions available
Scalability	Highly scalable with modular expansion
Operating Temperature	0°C to 60°C
