Siemens SIMATIC S7-1500 Automation System User Manual

Wiring
6.2 Operating the S7-1500 on grounded infeed
S7-1500 Automation System
56 System Manual, 01/2013, A5E03461182-01
Short-circuit and overload protection
Various measures as protection against short-circuits and overloads are required for setting
up a full installation. The nature of the components and the degree to which the required
measures are binding depends on the IEC (DIN VDE) regulation applicable to your plant
configuration. The table refers to the following figure and compares the IEC (DIN VDE)
regulations.
Table 6- 1 Components and required measures
Reference to
following figure
IEC 60364
(DIN VDE 0100)
IEC 60204
(DIN VDE 0113)
Shut-off device for control system,
sensors, and actuators
①
Main switch Disconnector
Short-circuit and overload protection:
In groups for sensors and actuators
②
③
Single-pole protection of
circuits
• With grounded
secondary circuit: fuse
unipolar
• otherwise: fuse all
poles
Load power supply for AC load circuits
with more than five electromagnetic
devices
④
Galvanic isolation by
transformer recommended
Galvanic isolation by
transformer recommended

Siemens SIMATIC S7-1500 Automation System Specifications

General

Series	SIMATIC S7-1500
Programming	TIA Portal (Totally Integrated Automation Portal)
Protection Class	IP20
CPU	Various models available (e.g., CPU 1511-1 PN, CPU 1518-4 PN/DP)
Controller Type	Modular Controller
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Communication Interfaces	PROFINET, PROFIBUS, Ethernet, OPC UA
Digital Inputs	Varies by model and expansion modules
Digital Outputs	Varies by model and expansion modules
Analog Inputs	Varies by model and expansion modules
Analog Outputs	Varies by model and expansion modules
Backplane Bus	High-speed backplane bus for fast communication between modules
Redundancy	Supported with specific models and configurations
Safety	Integrated safety functions available
Scalability	Highly scalable with modular expansion
Operating Temperature	0°C to 60°C
