17.11 Warnings
SIMOCODE PRO V PN FDI
Programming and Operating Manual, 05/2020, A5E44499659002A/RS-AA/001
161
Safety engineering
Indication
Meaning/Possible cause/Acknowledgement/Error processing
The DM-F Local / DM-F PROFIsafe enabling circuits have not
been opened and closed again within the configured time
period.
The function of the enabling circuit relay contacts can only be
tested when they are switched.
Further Information: See monitoring - interval for mandatory
testing (Page 67).
DM-F - Safety-oriented tripping The DM-F has tripped the enabling circuit for safety reasons.
The motor can only be switched on again after the DM-F
module enabling circuits have been closed.
Further Information: See Safety-oriented tripping.
DM-F - Simultaneity The DM-F Local has detected a discrepancy fault in the two-
channel sensor circuit.
Please check the contact blocks in the sensor circuit.
DM-FL - Feedback circuit The DM-F has detected a fault in the feedback circuit.
When the enabling circuit is being switched on, the feedback
circuit must be closed.
Please check the feedback circuit of the DM-F Local and/or
the DM-F PROFIsafe.
Monitoring
Indication
Meaning/Possible cause/Acknowledgement/Error processing
Warning level I> The maximum current has overshot the Warning level.
Check the application which is driven by the motor.
Further information: Current limits I> (upper level) (Page 50).
Warning level I< The maximum current has undershot the Warning level.
Check the application which is driven by the motor.
Further information: Current Limits I< (lower level) (Page 51).
Internal Earth Fault The internal earth-fault monitoring has been activated.
A fault current of too high a value is flowing.
Please check the motor connection cable for damage.
Acknowledge with "Reset".
Further information: Internal Earth fault (Page 43).
External Earth Fault The external earth-fault monitoring has been activated.
A fault current of too high a value is flowing.
Check the motor connection cable for damage.
Acknowledge with "Reset".
Further information: External Earth fault (Page 45).
