Byt
e
Bit No. Diagnostics events Effect of the event
1)
Quality status code DIAGNOSTICS bit Group
1 0 57 Static friction (limit 3) Uncertain, maintenance
demand
DIA_MAINTENANCE_ALARM M
1 58 Lower end stop monitor‐
ing (limit 1)
Good, maintenance re‐
quirement
DIA_MAINTENANCE M1
2 59 Lower end stop monitor‐
ing (limit 2)
Good, maintenance de‐
mand
DIA_MAINTENANCE_DEMAN‐
DED
M12
3 60 Lower end stop monitor‐
ing (limit 3)
Uncertain, maintenance
demand
DIA_MAINTENANCE_ALARM M
4 61 Upper end stop monitor‐
ing (limit 1)
Good, maintenance re‐
quirement
DIA_MAINTENANCE M1
5 62 Upper end stop monitor‐
ing (limit 2)
Good, maintenance de‐
mand
DIA_MAINTENANCE_DEMAN‐
DED
M12
6 63 Upper end stop monitor‐
ing (limit 3)
Uncertain, maintenance
demand
DIA_MAINTENANCE_ALARM M
7 64 Limit 1 for path integral
(100% strokes) excee‐
ded
Good, maintenance re‐
quirement
DIA_MAINTENANCE M1
2 0 65 Limit 2 for path integral
(100% strokes) excee‐
ded
Good, maintenance de‐
mand
DIA_MAINTENANCE_DEMAN‐
DED
M12
1 66 Limit 3 for path integral
(100% strokes) excee‐
ded
Uncertain, maintenance
demand
DIA_MAINTENANCE_ALARM M
2 67 Limit 1 for changes in di‐
rection exceeded
Good, maintenance re‐
quirement
DIA_MAINTENANCE M1
3 68 Limit 2 for changes of di‐
rection exceeded
Good, maintenance de‐
mand
DIA_MAINTENANCE_DEMAN‐
DED
M12
4 69 Limit 3 for changes of di‐
rection exceeded
Uncertain, maintenance
demand
DIA_MAINTENANCE_ALARM M
5 70 Limit 1 for position aver‐
age exceeded
Good, maintenance re‐
quirement
DIA_MAINTENANCE M1, P
6 71 Limit 2 for position aver‐
age exceeded
Good, maintenance de‐
mand
DIA_MAINTENANCE_DEMAN‐
DED
M12, P
7 72 Limit 3 for position aver‐
age exceeded
Uncertain, maintenance
demand
DIA_MAINTENANCE_ALARM M, P
3 0 73 PST reference time ex‐
ceeded (limit 1)
Good, maintenance re‐
quirement
DIA_MAINTENANCE M1
1 74 PST reference time ex‐
ceeded (limit 2)
Good, maintenance de‐
mand
DIA_MAINTENANCE_DEMAN‐
DED
M12
2 75 PST reference time ex‐
ceeded (limit 3)
Uncertain, maintenance
demand
DIA_MAINTENANCE_ALARM M
76 ...
80
Reserved - - -
Functions/operations using PROFIBUS PA
9.3 Cyclic data transfer
SIPART PS2 with PROFIBUS PA
Operating Instructions, 05/2019, A5E00127926-AC 233
