Functions
6.7 [2.08] Settings > Calibrations
Operating with the Local User Interface
Operating Manual, 06/2017, A5E31930478-05
115
You can set the following types of calibration:
Table 6- 3 Types of calibration
1-point zero gas calibration This calibration eliminates drifts in the zero point. The setpoint corresponds to the
actual value in the zero point.
1-point span gas calibration This calibration eliminates drifts in the span point by adjusting a sensitivity factor
accordingly. The setpoint corresponds to the actual value in the span point.
2-point calibration In this type of calibration, zero gas validation and span gas calibration take place
Scope/reference
Single calibration
Calibrations can be run as single or total calibrations. Only the selected measuring range is
calibrated in a single calibration, while the calibration parameters of all other measuring
ranges are not affected.
In a total calibration, at first the selected measuring range is calibrated as with single
calibration. However, the newly calculated calibration parameters of this leading measuring
range are transferred to all other measuring ranges. All measuring ranges can be adjusted
simultaneously in this way.
Information on the sequence of a calibration/validation is available at: → Sequence of a
calibration/validation (Page 116).
