Functions
6.19 [3.05] Maintenance & Diagnostics > Diagnostics values
Operating with the Local User Interface
Operating Manual, 06/2017, A5E31930478-05
217
Parameter
Description
C norm Cal
Normalized concentration measured value after calibration
Chopper frequency
C abs
Absolute concentration measured value
Measured value
CALOMAT 7: Evaluation of the measured signal quality
Table 6- 55 CALOMAT 7: [3.05.1.1] Measured signal
Parameter
Description
RM resistance
Current RM resistance
RT1 resistance Current RT 1 resistance
Resistance ratio
Resistance ratio between RM and RT 1 ?
S raw after low pass
Sensor signal converted into mV after application of the low-pass filter
C norm
Normalized concentration measured value
C lin PC
Linearized measured value with pressure compensation
Sensor temp.
Current sensor temperature
Temp. analyzer module
Show current temperature at analyzer
Measured value
Current measured value
6.19.1.2
Heating controller
Overview
In this menu you access status information/current values that you can use to check the
function of the heating controller.
You only have read access.
Component > "3. Maintenance & Diagnostics" > "05. Diagnostics values" > "1. Measured
signal diagnostics" > "3. Heating controller".
