Operation
4.2 Keyboard
Operating with the Local User Interface
56 Operating Manual, 06/2017, A5E31930478-05
Key functions
Keys of the numeric pad
Table 4- 3 Functions of the numeric keys
<0> ... <9>
You use the numeric keys to enter numerical values, e.g., in editing
windows. In addition, subordinate menu entries can be selected
directly by entering the menu number. Example: In the main menu,
the key combination <2> + <▪> + <0> + <8> + <▪> + <1> + <▪>
opens the menu [2.08.1]. See:
[2.08.1] Setpoints, tolerances, purg-
<▪>
Use this key to enter values with decimal places.
If you select menu entries with the numeric keys, pressing the <▪>
key opens the selected submenu or a selected menu entry.
<+/->
You can use this key to change the sign of a parameter value.
