6.12 [2.13] Setting > Process tag switchover
Operating with the Local User Interface
Operating Manual, 06/2017, A5E31930478-05
185
[2.13] Setting > Process tag switchover
6.12.1
Setting the process tag switchover
Procedure
1. Component > Main menu > "2. Settings" > "13. Process tag switchover"
The menu includes 13 navigation lines that you use to assign the process tags for
automatic process tag switchover. The menu entries have the following structure:
Structure of the navigation lines
1 Total
1)
Activation status
(on/off)
2 ... 13 >
2)
Designation of the pro-
cess tag
DO n/ ", .."
3)
Time
4)
Activation status
(on/off)
1)
Enable/disable all process tags for process tag switchover
2)
Designation of active process tag
3)
Digital output to which this process tag is connected. If the process tag is connected with
several digital outputs, it is identified with "", .."".
4)
Remaining time of the currently active process tag or set measuring time for inactive process
2. Assign process tags 1 to 12: Assigning process tags (Page 185).
3. Enable/disable all assigned process tags: Enabling/disabling all process tags (Page 186).
Assigning process tags
Requirements
For automatic process tag switchover, one or more digital outputs must be assigned to a
process tag. Check the corresponding assignments under Setting digital outputs (Page 155).
