Functions
6.11 [2.12] Settings > Gas path/process tag label
Operating with the Local User Interface
184 Operating Manual, 06/2017, A5E31930478-05
1. Component > Main menu > "2 Settings" > "12 Gas path/process tag label"
2. Set the design: "Gas path" parameter field.
Authorize access with Expert PIN, if necessary. Specify the design:
– "Shared" (standard for devices with only one analyzer module)
– "Separate" (one gas path for each of the installed analyzer modules)
Note
Operating mode and design of gas path:
Analyzer modules can be operated serial or parallel. If you only
use one analyzer module
or two serial analyzer modules, in the parameter box "Gas path" set the value to
"Shared".
If, on the other hand, you operate two parallel analyzer modules, choose the "Separate"
setting.
You will also find additional information i
n → Combined operation (Page 31).
3. Enter the process tag labels:
If you have assigned a shared gas path:
– Open the "Designation of process tag" parameter field.
– Enter a designation of up to seven characters in the text box.
If you have assigned a separate gas path:
– Open the "Process tag ..." parameter field.
– Enter a designation of the module-specific process tag of up to seven characters in
the text box.
– Repeat the process for the process tag of the second analyzer module.
The process tag label is displayed in the title bar.
References (Page 281)
Setting the sample gas purging time (Page 124)
