Description
3.6 Combined operation
Operating with the Local User Interface
Operating Manual, 06/2017, A5E31930478-05
31
Inputs/outputs of option modules OM2.1 and OM2.2
Table 3- 4 Inputs/outputs at a glance
The option module 2.1 has the following in-
puts/outputs:
•
6 digital outputs (3 digital outputs per analyzer
module): These digital outputs are assigned
to a fixed function, e.g. "SIL device" or "Gas
warning device"
• 6 analog outputs
The option module 2.2 has the following in-
puts/outputs:
• 4 analog inputs
• 4 digital inputs
• 6 analog outputs
Plug & measure (Page 44)
Analyzer module/installation location combinations
3.6.1.1
Combination of modules with hoses and pipes
Combinations of analyzer modules with hoses and analyzer modules with pipes are not
permitted:
• Only combine analyzer modules with hoses with other analyzer modules with hoses,
and only combine those with pipes with other analyzer modules with pipes.
• If required, you can adapt the modules with combination sets ("Combination set with
hoses"/"Combination set with pipes").
Additional information on combination sets is available from your Siemens partner:
→ Technical support (Page 279).
