Functions
6.10 [2.11] Settings > Pressure sensor selection
Operating with the Local User Interface
Operating Manual, 06/2017, A5E31930478-05
181
See also
Using device-internal pressure sensor (Page 181)
Measured signal (Page 215)
Note
Pressure compensation
With OXYMAT
7 and CALOMAT 7 analyzer modules, the pressure compensation is
activated automatically by the selection of the signal source.
With ULTRAMAT 7 analyzer modules, the activation status of the pressure compensation is
displayed in the menu "[3.05.1.2] Measured signal Part 2" (LUI). You can obtain further
inform
ation on activating this function from your service partner: → Technical support
(Page
279).
See also
Using device-internal pressure sensor (Page 181)
Measured signal (Page 215)
6.10.3
Using device-internal pressure sensor
Procedure
1. Component > Main menu > "2 Settings" > "11 Pressure sensor selection"
The currently set signal source and the currently measured pressure are displayed.
2. Set the signal source: "Signal source" parameter field.
– Authorize access with the Expert PIN, if necessary.
– Select "Device-internal" setting.
3. Repeat steps 1 and 2 for the other analyzer modules if two analyzer modules are installed
in your device.
The pressure value of the signal source can also be returned via MODBUS TCP or an
analog input instead of being created device-internal:
→ Integrating external pressure sensor via MODBUS TCP (Page 182).
→ Integrating external pressure sensor via analog inputs (Page 182).
