6.19 [3.05] Maintenance & Diagnostics > Diagnostics values
Operating with the Local User Interface
216 Operating Manual, 06/2017, A5E31930478-05
Parameter
Description
Pressure switch ref.
gas
Not displayed on OXYMAT 7 without pressure switch
p1 reference gas Reference gas pressure
Only for OXYMAT 7 with flow monitoring
p2 reference gas
Reference gas flow
Measured value
ULTRAMAT 7: Evaluation of the measured signal quality
Table 6- 53 ULTRAMAT 7: [3.05.1.1] Measured signal
Parameter
Description
IR source
Activation/deactivation by service personnel
Lock x TC
Lock y TC
S raw
Sensor signal converted to mV
Phase
Displays the angle value of signal "f" in the "degree" unit
Lock x 2f
Signal lock x, determined with 2f
Lock y 2f
Signal lock y, determined with 2f
R 2f
Raw value of 2f signal
Intensity I₀
Intensity I
0
for determining S
norm
S norm
Signal that is normalized with intensity I₀
Temp. comp. Zero point
Activation/deactivation by service personnel
Temp. compensation
Activation/deactivation by service personnel
Temp. detector
Current temperature value
Temp. chopper
Temp. analyzer module
S norm TC zero S
norm
with temperature compensation zero point
S norm TC pre
S
norm
with temperature pre-compensation
S norm auxco
The auxiliary characteristic coefficient of calculated S
norm
value
C lin
Linearized measured value
C lin after low pass
Linearized measured value after application of the low-pass filter
C lin TC post
Linearized measured value with temperature post compensation
Table 6- 54 ULTRAMAT 7: [3.05.1.2] Measured signal Part 2
Parameter
Description
Pressure compensation
Activation/deactivation by service personnel
p sample gas
Sample gas pressure
C lin PC
Linearized measured value with pressure compensation
Calibration correction
Activation/deactivation by service personnel
C norm
Normalized concentration measured value
