Functions
6.7 [2.08] Settings > Calibrations
Operating with the Local User Interface
120 Operating Manual, 06/2017, A5E31930478-05
Non-permissible calibration
Table 6- 8 Non-permissibility of calibrations with the following messages for pressure sensors
Message
No.
Text
[15]
Sample gas pressure outside tolerance.
[16]
Sample gas pressure uncertain.
[17] Reference gas flow measurement uncertain.
[18]
Reference gas pressure too low.
Table 6- 9 Non-permissibility of calibrations with the following voltage messages
Message
No.
Text
[64]
Power supply 3.3 V outside tolerance.
[65]
Operating voltage 24 V outside tolerance.
[66]
Power supply +5 V outside tolerance.
[67]
Power supply -5 V outside tolerance.
[69]
Power supply +22 V outside tolerance.
[70]
Reference voltage 2.5 V outside tolerance.
Table 6- 10 Non-permissibility of calibrations with the following additional messages
Message
No.
Text
[2]
Maximum warming-up time exceeded.
[87]
AM parameter memory faulty.
[89]
ADC faulty.
[128]
SPI communication faulty.
[144]
System error
[145]
Watchdog reset
[146]
Configuration faulty.
[150]
Parameter value invalid.
[153]
Factory synchronization of the electronics faulty.
See also
Permissibility of calibrations (Page 118)
