Functions
6.8 [2.09] Settings > Inputs/outputs
Operating with the Local User Interface
154 Operating Manual, 06/2017, A5E31930478-05
Total function check: signaling of function check at device level
Fct.check AM1/AM2 Function check at module level: signaling of function check for analyzer
modules 1 or 2
Low
Limit 1/2 Signaling of limit violation of limit 1 or 2. The measured value violates
Low
Signaling of "Calibration" operating state at module level
Calibration Total function check: signaling of "Calibration" operating state at device
High
Signaling contact: AutoCal signal contact, pulse 1000 ms
Signaling of active measuring range
Switching on of sample gas 1
Switching on of sample gas 2
Switchover of the process tag
Switching on zero gas for calibration
Switch external sample gas pump (on/off)
Signaling of device status "Fault"
Sync. (Function cannot current-
Synchronization of AutoCal sequences between several devices High
Signaling of device status "Maintenance alarm"
Signaling of device status "Maintenance demanded"
Signaling of device status "Maintenance required"
These functions are permanently assigned (no parameter assignment is possible):
Table 6- 25 Analyzer module: permanently assigned digital outputs
1 Safe measurement Enabled Digital outputs 21 or 24.
The relay serves as status relay that signals an exit from safe
measurement.
Fault Passive
2
Digital outputs 22 or 25.
The relay signals whether the module is in "Function check" mode.
3
Digital outputs 23 or 26.
The relay is used in analyzer modules to signal the fault status.
