Alarm, error, and system messages
7.6 Measured value status
Operating with the Local User Interface
Operating Manual, 06/2017, A5E31930478-05
277
Table 7- 10 Display of measured value status "Uncertain"
104 The measured value is uncertain because of a maintenance
demanded.
The measured value is still output,
amended by the symbol "?". (TLV and
120 The module is in the "Warming-up", "Calibration" or "Test mode"
state. The measured value is uncertain, because the module is
in warming-up or calibration state or inputs/outputs are in test
The measured value is still output.
79
The measured value is not available because the device is in the
initialization phase (startup) or measuring mode has not yet been
An initial value is output instead of the
measured value.
Table 7- 11 Display of measured value status "Bad"
0 The measured value is invalid because it is not available with the
existing device configuration.
• LUI:
– The measured value is no long-
er displayed in the TLV. "- - - "
is output instead.
– In submenus: The measured
value is still displayed but with
the qualifier symbol "x".
• SIMATIC PDM:
The substitute value 0.0 is output
instead of the measured value.
60 The measured value is invalid for one of the following reasons:
• Parameters are being downloaded
Effect/remedy: → Measured value qual-
ifier "0"
63 The measured value is invalid for one of the following reasons:
• Firmware is being downloaded
• The device is in the pause or standby state
A substitute value or the last valid
measured value is output instead of the
measured value.
36 The measured value is invalid because of a fault or a mainte-
Effect/remedy: → Measured value qual-
39 The measured value is invalid because of a fault or a mainte-
nance alarm.
A substitute value or the last valid
measured value is output instead of the
measured value.
40 The measured value is invalid because of a fault whose cause
can be found in the process (gas supply).
The measured value is still output.
43 The measured value is invalid because of a fault whose cause
can be found in the process (gas supply).
A substitute value or the last valid
measured value is output
instead of the
measured value.
