Siemens SIPROCESS GA700 User Manual

Appendix
A.5 MODBUS TCP
Operating with the Local User Interface
Operating Manual, 06/2017, A5E31930478-05
289
Object ID
Object name / description
Category
Type
Object
length
Coding
0x8D Component3_Code Extended UINT8 0x01 Table A-14 MODBUS TCP: Cod-
ing of gas components [Object ID
0x81, 0x87, 0x8D, 0x93, 0x99,
0x0000, 0x000C, 0x0018,
0x0024, 0x0030] (Page 298)
0x8E Component3_Name Extended STRING 0x20
0x8F Component3_UnitCode Extended UINT16 0x02 Table A-15 MODBUS TCP: Cod-
ing of component units [Object ID
0x83, 0x89, 0x8F, 0x95, 0x9B,
0x0001, 0x000D, 0x0019,
0x0025, 0x0031] (Page 299)
0x90
Component3_UnitName
Extended
STRING
0x08
0x91
Component3_RangeBegin
Extended
FLOAT32
0x04
0x92
Component3_RangeEnd
Extended
FLOAT32
0x04
0x93 Component4_Code Extended UINT8 0x01 Table A-14 MODBUS TCP: Cod-
ing of gas components [Object ID
0x81, 0x87, 0x8D, 0x93, 0x99,
0x0000, 0x000C, 0x0018,
0x0024, 0x0030] (Page 298)
0x94
Component4_Name
Extended
STRING
0x20
0x95 Component4_UnitCode Extended UINT16 0x02 Table A-15 MODBUS TCP: Cod-
ing of component units [Object ID
0x83, 0x89, 0x8F, 0x95, 0x9B,
0x0001, 0x000D, 0x0019,
0x0025, 0x0031] (Page 299)
0x96
Component4_UnitName
Extended
STRING
0x08
0x97
Component4_RangeBegin
Extended
FLOAT32
0x04
0x98
Component4_RangeEnd
Extended
FLOAT32
0x04
0x99 Component5_Code Extended UINT8 0x01 Table A-14 MODBUS TCP: Cod-
ing of gas components [Object ID
0x81, 0x87, 0x8D, 0x93, 0x99,
0x0000, 0x000C, 0x0018,
0x0024, 0x0030] (Page 298)
0x9A
Component5_Name
Extended
STRING
0x20
0x9B Component5_UnitCode Extended UINT16 0x02 Table A-15 MODBUS TCP: Cod-
ing of component units [Object ID
0x83, 0x89, 0x8F, 0x95, 0x9B,
0x0001, 0x000D, 0x0019,
0x0025, 0x0031] (Page 299)
0x9C
Component5_UnitName
Extended
STRING
0x08
0x9D
Component5_RangeBegin
Extended
FLOAT32
0x04
0x9E
Component5_RangeEnd
Extended
FLOAT32
0x04
0x9F Pressure1_Type Extended UINT8 0x01 Table A-16 MODBUS TCP: Cod-
ing of process value type [Object
ID 0x9F, 0xA1, 0xA3, 0xA5, 0xA7,
0x003C, 0x0049, 0x0054,
0x0060, 0x006C, 0x0078]
(Page 299)
