Siemens SIPROCESS GA700 User Manual

Appendix
A.5 MODBUS TCP
Operating with the Local User Interface
294 Operating Manual, 06/2017, A5E31930478-05
Address
Name / description
Register type
R/W
Type
Coding
0x0031 Component5_UnitCode Input / holding R UINT16 Table A-17
MODBUS TCP: Coding
of process value units
[Object ID 0xA0, 0xA2,
0xA4, 0xA6, 0xA9,
0x003D, 0x004A,
0x0055, 0x0061,
0x006D, 0x0079]
(Page 299)
0x0032
Component5_MeasValue
Input / holding
R
FLOAT32
DECIMAL
0x0033
0x0034
Component5_Status
1)
Input / holding
R
UINT32
Bit-Enum
0x0035
0x0036
Component5_Factor
Input / holding
R
FLOAT32
DECIMAL
0x0037
0x0038
Component5_Offset
Input / holding
R
FLOAT32
DECIMAL
0x0039
0x003A
RESERVED
0x003B
RESERVED
0x003C Pressure1_Type Input / holding R UINT8 Table A-16
MODBUS TCP: Coding
of process value type
[Object ID 0x9F, 0xA1,
0xA3, 0xA5, 0xA7,
0x003C, 0x0049,
0x0054, 0x0060,
0x006C, 0x0078]
(Page 299)
0x003D Pressure1_UnitCode Input / holding R UINT16 Table A-17
MODBUS TCP: Coding
of process value units
[Object ID 0xA0, 0xA2,
0xA4, 0xA6, 0xA9,
0x003D, 0x004A,
0x0055, 0x0061,
0x006D, 0x0079]
(Page 299)
0x003E
Pressure1_MeasValue
Input / holding
R
FLOAT32
DECIMAL
0x003F
0x0040
Pressure1_Status
1)
Input / holding
R
UINT32
Bit-Enum
0x0041
0x0042
Pressure1_Factor
Input / holding
R
FLOAT32
DECIMAL
0x0043
0x0044 Pressure1_Offset Input / holding R FLOAT32 DECIMAL
0x0045
0x0046 RESERVED
0x0047
RESERVED
0x0048
Pressure2_Type
Input / holding
R
UINT8
