Operation
4.1 Local User Interface (LUI)
Operating with the Local User Interface
Operating Manual, 06/2017, A5E31930478-05
53
Navigation-relevant keys
Table 4- 1 Functions of navigation-relevant keys
Keys
Function
Navigate to higher-level views/menus. Use the <MEAS> key to
return to the measured-value display in selection mode or to the
main view.
Navigate within a view/menu, and direct selection with the numeric
keys.
Navigate to subordinate views/menus. Direct selection with numer-
ic keys.
List of the current messages in the main view
This function represents a simplified operator control variant compared with menu [3.01.1].
Here, in the main view all the current messages can be displayed without changing to the
device menu.
"Current messages" are all messages still pending and all messages requiring
acknowledgement that have not yet been acknowledged. The last message entered in the
list is always at the top (sorted in descending order according to date and time). It is not
possible to filter messages.
The list view is permanently updated. If, for example, not only the incoming message but
also an outgoing message is registered, the device removes the corresponding list entry.
To display detailed information about the current messages in the main view, follow the
steps below:
1. If necessary, open the main view. To do this, press the <MEAS> key. Follow the
instructions on the display.
2. Display the list of current messages (display 4/4) in the main view. To do this, use the
<
▼
>/<
▲
> keys.
