DNP3.0/MODBUS FO
FO connector type ST connector receiver/transmitter
Connection for flush-mounted housing rear panel, slot “B”
Connection for surface-mounted
housing
in console housing
Transmission rate up to 19200 Baud
Optical wavelength λ = 820 nm
Laser class 1 according to
EN60825-1/-2
Using glass fibre 50/125 μm or
Using glass fibre 62.5/125 μm
Permissible optical signal attenuation max. 8 dB, with glass fibre 62.5/125 μm
Transmission distance max. 1.5 km
Ethernet electrical (EN 100) for IEC 61850 and DIGSI
Connection for flush-mounted housing rear panel, slot “B”
2 x RJ45 female connector
100BaseT acc. to IEEE802.3
Connection for surface-mounted
housing
in console housing
Test voltage (female connector) 500 V; 50 Hz
Transmission rate 100 MBit/s
Transmission distance 20 m
Ethernet optisch (EN100) für IEC 61850 und DIGSI
FO connector type ST connector receiver/transmitter
Connection for flush-mounted housing rear panel, slot “B”
Connection for surface-mounted
housing
not available
Transmission rate λ = 1310 nm
Optical wavelength 100 MBit/s
Laser class 1 according to
EN60825-1/-2
Using glass fibre 50 μm/125 μm or Using glass fibre 62,5 μm/125 μm
Permissible optical signal attenuation max. 5 dB, with glass fibre 62,5 μm/125 μm
Transmission distance max. 800 m
Analog output module (electrical)
2 Ports mit 0 mA bis 20 mA
Connection for flush mounted case rear panel, slot “B” and “D”
9-pole D-subminiature female connector
Connection for surface-mounted
housing
at the bottom side of the console housing
Test voltage 500 V; 50 Hz
Time Synchronisation Interface
Time synchronization
DCF77/IRIG B signal (telegram format IRIG-B000)
Connection for flush-mounted housing rear panel, slot “A”;
9-pole D-subminiature female connector
Connection for surface-mounted
housing
At the double-deck terminal on the case bottom
Signal nominal voltages Selectable 5 V, 12 V or 24 V
Test voltage 500 V; 50 Hz
Technical Data
4.1 General
198 SIPROTEC 4, 7VE61 and 7VE63, Manual
C53000-G1176-C163-3, Edition 10.2017
