2)
Cannot be delivered in connection with 9th digit = “B”. Only EN100 electrical possible (see Table A-2)
For surface mounting cases optical interfaces are not possible. In this case, please order a device with the appropriate
electrical RS485 interface, and the additional converters listed in Table.
Table A-2 Additional Device/Module for Surface-mounted Case
Protocol Converter/ Module Order Number Comments
Profibus DP
SIEMENS OLM
1)
6GK1502-2CB10 for single ring
6GK1502-3CB10 for twin ring
Modbus RS485/LWL
7XV5651-0BA00
DNP 3.0 820 nm RS485/LWL
1)
The converter requires an operating voltage of DC 24 V. If the available operating voltage is > DC 24 V the
additional power supply 7XV5810-0BA00 is required.
Port C (Service Interface) Pos. 12
DIGSI / Modem, electrical RS232 1
DIGSI / Modem, electrical RS485 2
For further interface options see Additional Information M 9
Additional Information M, Service and Additional Interface (Port C and Port D)
(Port C , Service Interface)
DIGSI 4, Modem RS232 +M 1 *
DIGSI 4, Modem RS485 +M 2 *
(Port D, Additional Interface)
Analog Outputs 2 x 0 to 20 mA or 4 to 20 mA +M * K
Functional Scope of the Device Pos. 14
Synchrocheck for up to 3 synchronizing points
(with switching to dead line / bus)
A
Paralleling function for 2 synchronizing points without balancing commands
(2 channels – independent procedures)
B
Paralleling function for 2 synchronizing points with balancing commands
(2 channels – independent procedures)
C
Paralleling function for 8 synchronizing points with balancing commands
(2 channels – independent procedures)
D
Additional Functions Pos. 15
without A
Protection and Network Decoupling Function
(Voltage and frequency protection, rate-of-frequency change protection and vector jump)
B
Zusatzanwendungen Pos. 16
without 0
Application for Traction Systems (f
N
= 16.7 Hz) 1
Ordering Information and Accessories
A.2 Ordering Information 7VE63
SIPROTEC 4, 7VE61 and 7VE63, Manual 227
C53000-G1176-C163-3, Edition 10.2017
