No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
5215 Frequency protection
undervoltage Blk (Freq
UnderV Blk)
Frequency
Prot.
OUT On
Of
f
On
Off
* LED BO 70 23
8
1 Yes
5232 Frequency protection: f1
picked up (f1 picked up)
Frequency
Prot.
OUT * On
Off
* LED BO 70 23
0
2 Yes
5233 Frequency protection: f2
picked up (f2 picked up)
Frequency
Prot.
OUT * On
Off
* LED BO 70 23
1
2 Yes
5234 Frequency protection: f3
picked up (f3 picked up)
Frequency
Prot.
OUT * On
Off
* LED BO 70 23
2
2 Yes
5235 Frequency protection: f4
picked up (f4 picked up)
Frequency
Prot.
OUT * On
Off
* LED BO 70 23
3
2 Yes
5236 Frequency protection: f1
TRIP (f1 TRIP)
Frequency
Prot.
OUT * On * LED BO 70 23
4
2 Yes
5237 Frequency protection: f2
TRIP (f2 TRIP)
Frequency
Prot.
OUT * On * LED BO 70 23
5
2 Yes
5238 Frequency protection: f3
TRIP (f3 TRIP)
Frequency
Prot.
OUT * On * LED BO 70 23
6
2 Yes
5239 Frequency protection: f4
TRIP (f4 TRIP)
Frequency
Prot.
OUT * On * LED BO 70 23
7
2 Yes
5503 >BLOCK Rate-of-
frequency-change prot.
(>df/dt block)
df/dt
Protect.
SP * * * LED BI BO
5504 >BLOCK df1/dt stage
(>df1/dt block)
df/dt
Protect.
SP On
Of
f
* * LED BI BO 72 1 1 Yes
5505 >BLOCK df2/dt stage
(>df2/dt block)
df/dt
Protect.
SP On
Of
f
* * LED BI BO 72 2 1 Yes
5506 >BLOCK df3/dt stage
(>df3/dt block)
df/dt
Protect.
SP On
Of
f
* * LED BI BO 72 3 1 Yes
5507 >BLOCK df4/dt stage
(>df4/dt block)
df/dt
Protect.
SP On
Of
f
* * LED BI BO 72 4 1 Yes
5511 df/dt is switched OFF
(df/dt OFF)
df/dt
Protect.
OUT On
Of
f
* * LED BO 72 5 1 Yes
5512 df/dt is BLOCKED (df/dt
BLOCKED)
df/dt
Protect.
OUT On
Of
f
On
Off
* LED BO 72 6 1 Yes
5513 df/dt is ACTIVE (df/dt
ACTIVE)
df/dt
Protect.
OUT On
Of
f
* * LED BO 72 7 1 Yes
Functions, Settings, Information
E.3 Information List
302 SIPROTEC 4, 7VE61 and 7VE63, Manual
C53000-G1176-C163-3, Edition 10.2017
