No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
5515 df/dt is blocked by under-
voltage (df/dt U< block)
df/dt
Protect.
OUT On
Of
f
On
Off
* LED BO 72 18 1 Yes
5516 Stage df1/dt picked up
(df1/dt pickup)
df/dt
Protect.
OUT * On
Off
* LED BO 72 9 2 Yes
5517 Stage df2/dt picked up
(df2/dt pickup)
df/dt
Protect.
OUT * On
Off
* LED BO 72 10 2 Yes
5518 Stage df3/dt picked up
(df3/dt pickup)
df/dt
Protect.
OUT * On
Off
* LED BO 72 11 2 Yes
5519 Stage df4/dt picked up
(df4/dt pickup)
df/dt
Protect.
OUT * On
Off
* LED BO 72 12 2 Yes
5520 Stage df1/dt TRIP (df1/dt
TRIP)
df/dt
Protect.
OUT * On * LED BO 72 13 2 Yes
5521 Stage df2/dt TRIP (df2/dt
TRIP)
df/dt
Protect.
OUT * On * LED BO 72 14 2 Yes
5522 Stage df3/dt TRIP (df3/dt
TRIP)
df/dt
Protect.
OUT * On * LED BO 72 15 2 Yes
5523 Stage df4/dt TRIP (df4/dt
TRIP)
df/dt
Protect.
OUT * On * LED BO 72 16 2 Yes
5581 >BLOCK Vector Jump
(>VEC JUMP block)
Vector Jump SP * * * LED BI BO
5582 Vector Jump is switched
OFF (VEC JUMP OFF)
Vector Jump OUT On
Of
f
* * LED BO 72 72 1 Yes
5583 Vector Jump is BLOCKED
(VEC JMP BLOCKED)
Vector Jump OUT On
Of
f
On
Off
* LED BO 72 73 1 Yes
5584 Vector Jump is ACTIVE
(VEC JUMP ACTIVE)
Vector Jump OUT On
Of
f
* * LED BO 72 74 1 Yes
5585 Vector Jump not in meas-
urement range (VEC
JUMP Range)
Vector Jump OUT On
Of
f
* * LED BO 72 75 1 Yes
5586 Vector Jump picked up
(VEC JUMP pickup)
Vector Jump OUT * On
Off
* LED BO 72 76 2 Yes
5587 Vector Jump TRIP (VEC
JUMP TRIP)
Vector Jump OUT * On * LED BO 72 77 2 Yes
5588 >Failure: VT Ua (MCB
tripped) (>FAIL: VT Ua)
P.System
Data 1
SP On
Of
f
* * LED BI BO 41 83 1 Yes
5589 >Failure: VT Ub (MCB
tripped) (>FAIL: VT Ub)
P.System
Data 1
SP On
Of
f
* * LED BI BO 41 84 1 Yes
Functions, Settings, Information
E.3 Information List
SIPROTEC 4, 7VE61 and 7VE63, Manual 303
C53000-G1176-C163-3, Edition 10.2017
