Application and functions
1.3 PG routing
TIM 1531 IRC
Operating Instructions, 02/2018, C79000-G8976-C468-02
17
Web server connections (WBM)
●
HTTP/HTTPS
The TIM has an integrated Web server with which you can connect from a PC via
HTTP/HTTPS. Connections are possible via LAN or WAN
The Web pages display diagnostics information and configuration data.
You will find information on the content and operation in the section The Web server
(WBM) (Page 263).
1.3
PG routing
PG routing between telecontrol modules
PG routing is supported between the modules listed in the table and via the specified media.
A requirement for the CPs is that the options "S7 communication" and "Online functions" are
enabled in the "Communication types" parameter group.
Module
Medium (protocol)
TIM 1531 IRC
TIM 4R-IE
TIM 3V-IE / TIM
3V-IE Advanced
CP 1243-8 IRC
CP 1542SP-1 IRC
TIM 1531 IRC
Ethernet (S7)
Ethernet (MSC)
RS-232
Ethernet (S7)
Ethernet (MSC)
-
Ethernet (S7)
Ethernet (MSC)
-
Ethernet (S7) Ethernet (S7)
TIM 4R-IE
Ethernet (S7)
Ethernet (MSC)
-
Ethernet (S7)
Ethernet (MSC)
RS-232
Ethernet (S7)
Ethernet (MSC)
RS-232
-
-
TIM 3V-IE
Ethernet (S7)
Ethernet (MSC)
-
Ethernet (S7)
Ethernet (MSC)
RS-232
Ethernet (S7)
Ethernet (MSC)
RS-232
-
-
CP 1243-8 IRC
Ethernet (S7)
-
-
-
-
CP 1542SP-1 IRC
Ethernet (S7)
-
-
-
-
"RS-232" means communication via dedicated line or dialup network.
See the performance data and the configuration limits for the number of supported
connections.
