Siemens TIM 1531 IRC User Manual

Block library TeleControl ST7
5.7 Master copies
TIM 1531 IRC
Operating Instructions, 02/2018, C79000-G8976-C468-02
171
Address
range:
Output bytes
QB0 ... QBn
PQB0 ... PQBn
Memory bytes
MB0 ... MBn
LB0 ... LBn
Data bytes
DBm.DBB0 ... n
Ex
planation:
Output byte
Specify the memory area (1 to 4 bytes) of the binary information to be output
in the binary information.
Output bytes from the process image output, I/O bytes directly to digital output
modules, data bytes from a data block and memor
y bytes can be mixed.
If you do not require parameters, simply leave them open.
For information on reading out the time stamp received with the data using the
user program, see the section Time stamp (Page 154).
Parameter:
NewData
Explanation:
For the declaration, data type, range of values, default and function, refer to
the section
Reoccurring parameters (Page 144).
The output "NewData" is always set to TRUE for one OB1 cycle when the FB
has received new data and output it to the output bytes "OutputByte_1" to
"OutputByte_4"
5.7.1.10
Command typical Cmd01B_S
Function
Send 1 byte commands with 1-out-of-8 check
The 1-out-of-8 check is performed by the data point typical.
The 1-out-of-n check is performed by FC Safe.
Note
FC Safe required
With Cmd01B_S, data can only be transmitted when FC Safe
is linked in cyclic program.
Parameter
Parameter:
PartnerNo
PartnerObjectNo
For a description, see section Reoccurring parameters (Page 144).
