Application and functions
1.9 Expansion of SINAUT projects
TIM 1531 IRC
Operating Instructions, 02/2018, C79000-G8976-C468-02
29
The procedure for configuration of a communication module for the expansion is as follows:
1. Configuration of a placeholder (proxy) for an S7-1200/1500 module in the STEP 7 V5
project
The proxy receives the SINAUT-specific communication, connection and address
parameters.
2. Export the configuration data (SDBs) of the proxy from STEP 7 V5 as a text file.
3. Import the configuration data of the proxy into a compatible module in STEP 7 Basic /
Professional.
The new module adopts the SINAUT-specific communication, connection and address
parameters from STEP 7 V5.
4. Complete the configuration of the new module in STEP 7 Basic / Professional.
This procedure is supported by the following modules:
Table 1- 2 Module migration from STEP 7 V5 to STEP 7 Basic / Professional (TIA Portal)
Module function for STEP 7 V5 project ex-
pansion
S7-1200/1500 module in STEP 7 Basic /
Professional
TIM (function) for
expansion
Proxy to be used in
the catalog
TIM 3V-IE Advanced PROXY
CP1243-8 IRC
⇒ CP 1243-8 IRC STEP 7 Basic
TIM 4R-IE PROXY
⇒ TIM 1531 IRC STEP 7 Professional
TIM 4R-IE Stand-
PROXY
⇒ TIM 1531 IRC STEP 7 Professional
Note
TIM 4R-IE Stand-alone for S7-400 becomes TIM 1531 IRC
A TIM
4R-IE Stand-alone required in STEP 7 V5 that is assigned to a CPU-400 must be
1531 IRC for the expansion of classic SINAUT projects in STEP 7
4R-IE Stand-alone can only be created in new projects that are configured exclusively
EP 7 Professional.
You can find details on configuration in the section STEP 7 V5 configuration of the proxy
(Page 313).
Requirements for the expansion
Furthermore, the following requirements apply to importing configuration data from
STEP 7 V5 to STEP 7 Basic / Professional.
Additional modules that are not listed here are available for new projects in STEP 7 Basic /
Professional.
