Siemens TIM 1531 IRC User Manual

TIM 1531 IRC
Operating Instructions, 02/2018, C79000-G8976-C468-02
293
Technical specifications
8
8.1
Technical specifications
Table 8- 1 Technical specifications - TIM 1531 IRC
Technical specifications
Article number
6GK7 543-1MX00-0XE0
Attachment to Industrial Ethernet
Quantity
• 1 x gigabit interface (X1)
• 2x Fast Ethernet interface (X2, X3)
Design
RJ-45 jack, galvanically isolated
Properties Half duplex/full duplex, autocrossover, autonegotiation
Standard / transmission speed
• Standard
• Transmission speeds
Gigabit interface (X1)
• 1000BASE-T, IEEE 802.3ab
• 10 / 100 / 1000 Mbps
Fast Ethernet interfaces (X2 / X3)
• 100BASE-TX, IEEE 802.3-2005
• 10 / 100 Mbps
Permitted cable lengths (Ethernet)
(Alternative combinations per length range) *
0 ... 55 m
• Max. 55 m IE TP Torsion Cable with IE FC RJ45 Plug 180
• Max. 45 m IE TP Torsion Cable with IE FC RJ45 + 10 m TP Cord via
IE FC RJ45 Outlet
0 ... 85 m
• Max. 85 m IE FC TP Marine/Trailing/Flexible/FRNC/Festoon/Food Cable with
IE FC RJ45 Plug 180
• Max. 75 m IE FC TP Marine/Trailing/Flexible/FRNC/Festoon/Food Cable +
10 m TP Cord via IE FC RJ45 Outlet
0 ... 100 m
• Max. 100 m IE FC TP Standard Cable with IE FC RJ45 Plug 180
• Max. 90 m IE FC TP Standard Cable + 10 m TP Cord via IE FC RJ45 Outlet
Serial interface for connection to the transmission device
Quantity
1 x serial interface (X4)
Design
9-pin D-sub male connector, isolated
Standards
RS-232 / RS-485 (can be changed in the configuration)
Transmission speeds
300 ... 115 200 Bps (depending on the connected modem)
Power supply
Design Socket (X80) with terminal block 1 two-pole terminal block with polarity pro-
tection
Power supply
• Type of voltage
• Permitted low limit
• Permitted high limit
• 24 VDC
• 19.2 V
• 28.8 V

Siemens TIM 1531 IRC Specifications

General

Brand	Siemens
Model	TIM 1531 IRC
Category	Controller
Language	English
