The Web server (WBM)
6.3 General functions of the WBM
TIM 1531 IRC
264 Operating Instructions, 02/2018, C79000-G8976-C468-02
With HTTPS connections via the Internet when you log in the first time, a warning can
appear that the Web page is not secure or that the certificate is not trustworthy. If you are
sure that you have entered the correct address, ignore the message. If necessary add the
connection to the exceptions (depending on the Web browser).
The logon window of the TIM opens.
3. In the "User name" input box, enter the name of a user or administrator configured in
STEP 7.
The rights assigned in "Global security settings" of the STEP 7 project apply.
4. Enter the corresponding password in the "Password" input box.
5. Click the "Log in" button.
The Web server opens with the start page:
General functions of the WBM
Displays and symbols in the title bar
The displays and symbols in the WBM title bar have the following meaning:
Name of the currently logged in user
User logout
Number of connections to a PC
Date and time of the last page update of the WBM in local time of the
TIM (yyyy-mm-dd hh:mm:ss)
Displays the set WBM language
You set the WBM language with the setting of the browser being
used.
The following languages are supported:
• German
• English
The automatic update of the WBM display is enabled. The data is
fetched at the interval configured under "System > Web server".
The automatic update of the WBM display is disabled.
Switches on the automatic update of the WBM display.
Switches off the automatic update of the WBM display.
Prints out the current WBM page
