Siemens TIM 1531 IRC - Analog Value Typical Ana04 W_S

Block library TeleControl ST7
5.7 Master copies
TIM 1531 IRC
160 Operating Instructions, 02/2018, C79000-G8976-C468-02
Parameter:
NewData
For the declaration, data type, range of values, default and function, refer to
the section Reoccurring parameters (Page 144).
Typical
-
specific r
e-
sponse:
Whenever the FB has received new data and has output it to the outputs
"AnalogOutput_1" to "AnalogOutput_4", the "NewData" output is set to TRUE
for one OB1 cycle.
5.7.1.6
Analog value typical Ana04W_S
Function
Send 4 analog values as 16 bit values
Ana04W_S transfers the 4 analog values alternatively:
● As instantaneous values
At the time of the transfer, the currently pending analog value is acquired and transferred
to the partner.
● As mean values
The pending analog value is accumulated at selectable intervals. At the time of the
transmission, a mean value is formed from the total value and transferred to the partner.
Note
Common processing of the four analog values
The processing parameters such as threshold, smoothing factor etc. exist only once in a
typical. These parameters apply to all 4 analog values in common; in other words, it is not
possible to set the parameters for the individual analog values. For this
reason, each typical
should only acquire analog values that should be processed in the same way.
Parameter
Parameter:
PartnerNo
PartnerObjectNo
Enabled
ImageMemory
Conditional
Unconditional
For a description, see section Reoccurring parameters (Page 144).
