1.9 Expansion of SINAUT projects
TIM 1531 IRC
28 Operating Instructions, 02/2018, C79000-G8976-C468-02
1.9
Expansion of SINAUT projects
1.9.1
Modules for new SINAUT projects and those to be expanded
New SINAUT projects in the TIA Portal
For new SINAUT projects, the following modules can be configured in STEP 7 Basic /
Professional V15 (TIA Portal) without pre-configuration in STEP 7 V5.
Table 1- 1 Configuring modules in STEP 7 Basic / Professional
Module name (firmware
version)
Usable modules in STEP 7 Basic / Professional as of V15
Catalog module
STEP 7 version
TIM 3V-IE (V2.6) TIM 3V-IE STEP 7 Profession-
al
TIM 3V-IE Advanced (V2.6) TIM 3V-IE Advanced STEP 7 Profession-
al
TIM 4R-IE (V2.6)
• TIM 4R-IE
• TIM 4R-IE Stand-alone
STEP 7 Profession-
al
CP 1243-8 IRC (V3.0)
CP 1243-8 IRC
STEP 7 Basic
TIM 1531 IRC (V1.0) TIM 1531 IRC STEP 7 Profession-
al
CP 1542SP-1 IRC (V2.0) CP 1542SP-1 IRC STEP 7 Profession-
al
Extension of existing SINAUT projects in the TIA Portal
SINAUT projects with TIM modules for the SIMATIC S7-300 and S7-400 series, which were
configured in STEP 7 V5, can be extended with communication modules of the S7-
1200/1500 series which are configured in STEP 7 Basic or STEP 7 Professional in the TIA
Portal.
The following modules are available as communication modules for expanding existing
SINAUT systems:
● CP 1243-8 IRC
As of STEP 7 Basic V13.0 SP1
● TIM 1531 IRC
As of STEP 7 Professional V15
To avoid having to create, configure and program the entire STEP 7 V5 project in STEP 7
Professional, the STEP 7 V5 project can be expanded by S7-1200/1500 stations with
compatible communication modules.
