The Web server (WBM)
6.7 Diagnostics
TIM 1531 IRC
270 Operating Instructions, 02/2018, C79000-G8976-C468-02
6.6.2
Operating status
Operating statuses
Apart from using this WBM page you can also execute the functions described below using
the switch of the TIM, see section Switch (Page 35).
The buttons have the following functions:
●
Run a restart
When restarting, existing telecontrol connections are interrupted and cyclic processing
stops. The TIM restarts.
●
Reset to factory settings
Resets the TIM to the factory settings. During this all parameters are reset to the initial
statuses as shipped and the TIM restarts.
If you use an SD card and you want to reset the TIM to the factory settings, you must pull
the SD card before resetting. If the SD card remains inserted, the TIM starts up again
with the configuration data on the SD card.
When pulling the SIM card, remember the information in section Resetting to factory
settings (Page 287).
Note
Data loss: Note the effects of resetting
Before you reset, note the effects, see section
Inserting the SD card (Page 47). There,
you will also find the LED patterns during the reset.
6.7
Diagnostics
6.7.1
Diagnostics messages
Diagnostics messages
Table
The table lists the last diagnostics events to occur on the TIM with the following information:
●
Number
Consecutive number
●
Time
Time of the diagnostics event
