Diagnostics and upkeep
7.6 Processing status of the messages (SMS / e-mail)
TIM 1531 IRC
290 Operating Instructions, 02/2018, C79000-G8976-C468-02
7.6
Processing status of the messages (SMS / e-mail)
Processing status of messages
If this option is enabled in the "Trigger" tab of the message configuration of STEP 7, a status
is output on the CP that provides information about the processing status of the sent
message. The status is written to a PLC tag of the type DWORD. Select this tag via the "PLC
tag for processing status" box.
Processing status of the telecontrol e-mails
The meaning of the statuses is as follows:
Table 7- 3 SMS: Meaning of the status ID output in hexadecimal format
Status
Meaning
0000
Transfer completed free of errors
0001 Error in the transfer, possible causes:
• SIM card invalid
• No network
• Wrong destination phone number (number not reachable)
Table 7- 4 E-mail: Meaning of the status ID output in hexadecimal format
Status
Meaning
0000
Transfer completed free of errors
82xx Other error message from the e-mail server
Apart from the leading "8", the message corresponds to the three-digit error number of the
SMTP protocol.
8401 No channel available. Possible cause: There is already an e-mail connection via the mod-
ule. A second connection cannot be set up at the same time.
8403
No TCP/IP connection could be established to the SMTP server.
8405
The SMTP server has denied the login request.
8406 An internal SSL error or a problem with the structure of the certificate was detected by the
SMTP client.
8407
Request to use SSL was denied.
8408
The client could not obtain a socket for creating a TCP/IP connection to the mail server.
8409 It is not possible to write via the connection. Possible cause: The communications partner
reset the connection or the connection aborted.
8410 It is not possible to read via the connection. Possible cause: The communications partner
terminated the connection or the connection was aborted.
8411
Sending the e-mail failed. Cause: There was not enough memory space for sending.
8412
The configured DNS server could not resolve specified domain name.
8413
Due to an internal error in the DNS subsystem, the domain name could not be resolved.
8414
An empty character string was specified as the domain name.
