Siemens TIM 1531 IRC User Manual

Technical specifications
8.1 Technical specifications
TIM 1531 IRC
294 Operating Instructions, 02/2018, C79000-G8976-C468-02
Technical specifications
Cable cross-section connectable to
the terminal block
• Without wire end ferrule
• With wire end ferrule
• With TWIN wire end ferrule
• 0.2 .. 2.5 mm
2
/ AWG 24 .. 13
• 0.25 .. 1.5 mm
2
/ AWG 24 .. 16
• 0.5 .. 1.0 mm
2
/ AWG 20 .. 17
Further electrical data
Details for a TIM with all interfaces connected:
Current consumption (typical)
160 mA
Effective power loss (typical)
4 W
Overvoltage category according to
IEC / EN 60664-1
Category II
Permitted ambient conditions
Ambient temperature During operation with the rack in-
stalled horizontally
0 °C ... +70 °C
During operation with the rack in-
stalled vertically
0 °C ... +50 °C
During storage
-40 ℃ to +70 ℃
During transportation
-40 ℃ to +70 ℃
Relative humidity
During operation
≤ 60 % at 25 °C, no condensation
Permitted contaminant concentration
Corrosive gas test according to ISA-S71.04 severity level G1, G2, G3
• SO
2
• H
2
S
• < 0.5 ppm
• < 0.1 ppm
Design, dimensions and weight
Module format
Compact module S7-1500
Degree of protection
IP20
Weight
525 g
Dimensions (W x H x D)
70 x 147 x 129 mm
Installation options
DIN rail for SIMATIC S7-1500 (article numbers 6ES7590-1Axx0-0AB0)
Product functions **
*
For details, refer to the IK PI catalog, cabling technology
**
You will find further characteristics and performance data in the section Application and
functions (Page 13).
