Block library TeleControl ST7
5.7 Master copies
TIM 1531 IRC
248 Operating Instructions, 02/2018, C79000-G8976-C468-02
As the output value, FC TestCopy returns a count value in DBW12 (Recv_TgramCounter) of
the DB TestCopyData for the frames received since setting mode 1, 2 or 3 that match the
filter criteria.
The number of send frames is entered in DBW26 (Sendcv_TgramCounter).
In DBB28, you receive a return value that indicates the errors that occurred during
processing of the FC:
● FC_RetVal = 0
No error
● FC_RetVal = 1
The specified DB TestCopyData is too short.
● FC_RetVal = 10d
The mode entered in DBB0 is not defined.
In addition, the following special filters are available for the RecvCopy or SendCopy function:
Name (symbol) *
Permitted values
(hex.)
Meaning
Xxxx_TgrmType
FF
Copy all frame types (TA) to DB TestCopyData
00 Copy only spontaneous Org. frames (TA = 0)
11
Copy only queried Org. frames (TA = 1).
22 Copy only spontaneous data frames (TA = 2).
33
Copy only queried data frames (TA = 3).
01
Copy Org. frames with TA = 0 or 1
23
Copy data frames with TA = 2 or 3
Any combination
Copy any 0, 1, 2, 3 combinations.
Xxxx_DestSubscr All permitted sub-
scribers
Filter for the dest. subscriber no. in the frame
-1
Copy all frames regardless of the dest. subscriber no.
Xxxx_DestObject All permitted ob-
jects
Filter for the dest. object no. in the data frame.
-1
Copy all frames regardless of the dest. object no.
Xxxx_SourceSubscr All permitted sub-
scribers
Filter for the source subscriber no. in the frame
-1
Copy all frames regardless of the source subscriber no.
Xxxx_SourceObject All permitted ob-
jects
Filter for the source object no. in the data frame
-1
Copy all data frames regardless of the source object no.
Xxxx_StartIndex All permitted in-
dexes
Filter for the start index no. in the data frame
-1
Copy all data frames regardless of the start index no.
* "Xxxx": Placeholder for "Recv" or "Send"
The desired filter tags can be easily added using the tag names of the TestCopy DB.
