Siemens TIM 1531 IRC User Manual

Accessories
B.3 Routers, modems, antennas
TIM 1531 IRC
Operating Instructions, 02/2018, C79000-G8976-C468-02
309
Figure B-1 ANT794-4MR GSM/GPRS antenna
Short name
Article number
Explanation
ANT794-4MR 6NH9 860-1AA00 Quadband antenna (900, 1800/1900 MHz, UMTS);
weatherproof for indoor and outdoor areas; 5 m
connecting cable connected permanently to the
antenna; SMA connector, including installation
bracket, screws, wall plugs
Flat antenna ANT794-3M
Figure B-2 Flat antenna ANT794-3M
Short name
Article number
Explanation
ANT794-3M 6NH9 870-1AA00 Flat antenna (900, 1800/1900 MHz); weatherproof
for indoor and outdoor areas; 1.2 m connecting cable
connected permanently to the antenna; SMA con-
nector, including adhesive pad, screws mounting
possible
You will find detailed information in the device manual. You will find this on the Internet on
the pages of Siemens Industry Online Support:
Link: (https://support.industry.siemens.com/cs/ww/en/view/48729835)
