STEP 7 V5 configuration of the proxy
C.5 Exporting configuration data
TIM 1531 IRC
318 Operating Instructions, 02/2018, C79000-G8976-C468-02
4. Click the "Save" button.
The "Save as" dialog opens.
Figure C-5 Export of the configuration data of a proxy in the example as the file
"sdbs_CP12438-01.txt".
5. In the file directory of the configuration PC/PG, select a suitable directory for the file of the
configuration data.
6. Select a unique name for the file of the configuration data of this proxy.
Retain the default file type TXT file.
7. Click "Save".
A text file with the data of all SINAUT SDBs is saved in the file directory.
Note
TXT file for STEP 7 in the TIA Portal.
You then need the exported text file to import it into the respective successor module in
STEP
7 Basic / Professional.
