CA42/50/52 Fundamentals & initial start-up Chapter 2
11
RADAR
TX
Hotkey to radar display. Hold two seconds to start transmission, go in
Standby or Power off.
CHART
GOTO
Hotkey to Chart 1 i.e. jumps to window on the screen with Chart 1
display; if none: inserts Chart 1 in active window.
Activates INFO window with choice of navigation modes.
PLOT
Plots down the actual ship/cursor position on chart. Activates INFO
window with the possibility of plotting a waypoint, route, line, etc.
ADJ
Activates radar control menu + toggles between 1
st
and 2
nd
half of the
control menu in half screen displays.
0-9
A-Z
The alpha-numeric keys inserts and selects data in data displays.
Keys 1-9 are also Quick scales – selects fixed scales for charts or fixed
ranges for radar. The 0 key will center the cursor/ship on the chart and
activate/deactivate ‘off-center to cursor’ on the radar display.
CLR
Turns cursor off in chart display. Deletes data in enter or edit mode.
From radar control menu: Returns Tune, Gain or Sea to AUTOmatic
mode, and clears the EBL and VRM markers.
PWR
Calls up a window where you can adjust the lighting in the screen,
background light in keypad, and select Daylight displays, Night display
or custom made display. Hold two seconds to turn the power off.
