CA42/50/52 Setup menu Chapter 10
139
10.3 Interface setup, alarm/log
MENU
Call up the menu bar, and…
8,3
load Interface setup alarm/log display
Interface setup, alarm:
Output (pin 1,2): OFF
Alarm stand-by level: LOW
Interface setup, pos-status:
Output (pin 4,6): OFF
Pos-status, stand-by level: LOW
Interface setup, log:
Output (pin 5,6): ON
MENU
Exit Accept
ENT
The stand-by level can be either: LOW = 0 volt or HIGH = 5 volt.
Use cursor to move around in display, and…
+/-
toggle between available settings with the +/- keys
ENT
Confirm entry, or…
MENU
exit function without making any changes
To Next Page
