Simrad CA42 User Manual

CA42/50/52 Fundamentals & initial start-up Chapter 2
13
2.4 Menu layout
_1_
CHART
_2_
POS
_3_
WP/RTE
_1_ Chart 1 1:26400000 _1_ Position _1_ WP list
_2_ Chart 2 1:6600000 _2_ Dual speed _2_ Routes
_3_ C-MAP cartridges _3_ Speed, course & depth _3_ Route calculation
_4_ Speed diagram _4_ Lines
_5_ Satellites _5_ Start track
_6_ DGPS _6_ Stop track
_7_ SDGPS _7_ Tracks
_8_ Targets
_4_
NAV (OFF)
_5_
ECHO
_6_
RADAR
_1_ Highway _1_ Echo 50kHz _1_ Radar
_2_ Waypoint navigation _2_ Echo 200kHz _2_ Dual radar
_3_ Route navigation _3_ Bottom expansion 50kHz _3_ Radar setup
_4_ Track navigation _4_ Bottom expansion 200kHz
_5_ Anchor guard _5_ VRM expansion 50kHz
_6_ Trim & highway _6_ VRM expansion 200kHz
_7_ Set & drift _7_ Depth & temperature diagram
_8_ Echosounder setup
_4_
NAV (ON)
_1_ Highway
_2_ Turn NAV off
_3_ WP advance
_4_ Restart to approaching point
_5_ ETA & AVN
_6_ Trim & highway
The NAV menu is dynamic and will adapt to the
function which is currently active.
← When this menu appears, then one of the
Navigation modes is active.
_7_ Set & drift
