CA42/50/52 Position menus Chapter 4
43
4.5 Satellite status
MENU
Call up the menu bar, and…
2,5
load satellite status display
The display will show which satellites are currently being used for
computation of data. It will show their position together with SNR –
Signal to Noise Ratio. The bottom line shows the status of all the satel-
lites in the GPS system, starting from left to right with the numbers 1
to 32, or the legend: No almanac.
Satellite status (bottom line):
+ indicates the satellite is healthy
- excluded or non-existing satellite
0 satellite data is faulty
* satellite is manually excluded
You may want to exclude a satellite manually in case a particular
satellite is disturbing the navigation.
ENT
Open for change, and…
Place the cursor on the satellite in the bottom line you wish to exclude
GPS: D HDOP: 1.6 DOP limit: 8
SAT
nr
>++++++++ ++ - - ++++ +++++ - ++ + +++-+++-<
2
4
7
8
9
11
13
15
16
21
60
°
30
°
W
E
SNR
050100
SAlarm:OFF
0
°
N
7
2
4
9
11
13
15
16
21
