Simrad CA42 User Manual

CA42/50/52 C-MAP attributes Appendix C
163
The optional detailed C-MAP NT+ cards can provide numerous of functions
which are accessible via symbols presented on the electronic chart. Place the
cursor on a C-MAP object e.g. a buoy or light to call up a small data window
with details on the object. The data window will stay on screen for about 10
seconds or till cursor is moved. For expanded information, place the cursor on a
C-MAP object and press [ENT] to call up an info window:
Scale: 1:200000
-Actual chart scale.
No user data
at cursor position
1
Edit user data
-Inactive function.
2
Chart info
-See details below.
3
Find nearest port services
-See details below.
4
Bearing & dist. from A to B
-Section 3.3 Info windows.
5
Lock cursors
9
Chart setup
-Section 3.4 Chart setup.
0
Cursor to center
-Section 3.3 Info windows.
GOTO
Select NAV mode
-Section 3.3.8 GOTO function.
PLOT
Plot new data
-Section 3.3.9 PLOT function.
PAGE
More user data
-Inactive function.
MENU
Exit
-Exit info window.
2
Chart info will provide information on the C-MAP objects e.g. Light-
house, Depth area, Fishery zone, Navigation mark, Buoy, Fog signal,
etc.
