CA42/50/52 Chart menus and INFO windows Chapter 3
22
3.3 INFO windows
A number of pop-up INFO windows are available mainly from active
chart display. Only a few of the functions in the INFO windows can be
accessed from data displays and other displays. Refer to sections 3.3.x.
3.3.1 Cursor inactive
ENT
With chart in active window, and with cursor off, press
[ENT]
to call
up an info window with the following to choose from:
Scale: 1:6600000
-Actual chart scale.
No user data
at ship’s position
1
Edit user data
-Inactive function.
2
Chart info
-Refer to Appendix C.
3
Find nearest port services
-Refer to Appendix C.
4
Bearing & dist. from A to B
-Inactive function.
5
Lock cursors
-Inactive function.
9
Chart setup
-Refer to section 3.4.
0
Ship to center
GOTO
Select NAV mode
PLOT
Plot new data
PAGE
More user data
MENU
Exit
-Exit info window.
0
Ship to center will adjust the chart to place the ship’s position in the
center of the chart display.
GOTO
Select NAV mode will activate Navigation mode.
PLOT
Plot new data will give you the choice of entering the ship’s position
as Eventmark, waypoint or target.
PAGE
More user data will toggle between available data on the ship’s
position.
