CA42/50/52 Chart menus and INFO windows Chapter 3
30
3.3.9 PLOT function
The CAXX is designed to make navigation easy and safe. Making
routes, drawing lines and plotting waypoints, etc. can all be done
directly on the chart. Very straightforward and uncomplicated.
The PLOT function is available from various displays as indicated
below.
PLOT
With any other display than chart or echo display in active window,
press
[PLOT]
to insert ship’s/cursor’s position as waypoint
PLOT
With chart in active display, press
[PLOT]
to call up an INFO window
with the following to choose from:
PLOT new data
PLOT
Plot eventmark - ship
1
Plot waypoint - cursor
2
Insert waypoint - ship
3
Insert waypoint - cursor
4
Plot waypoint from echogram
5
Make route
6
Draw line
7
Plot target - cursor
8
Set vertical mark
MENU
Exit
PLOT
From any display:
Plot and save ship’s position as a waypoint including actual depth.
1
From active chart display with cursor ON:
Plot and save cursor position as a waypoint.
2
From active chart display:
Plot and save ship’s position as a waypoint including actual depth;
insert a location name (cf.section 2.6), adjust the position by keying in
new figures, change the symbol (cf.section 2.5).
