CA42/50/52 Fundamentals & initial start-up Chapter 2
14
_7_
MISC
_1_ Wind
_2_ MOB position
_3_ DSC alarm
_4_ Data transfer
_8_
SETUP
_1_ Speed alarm, units & language
_2_ NMEA interface
_3_ Alarm/log output
_4_ Decca lanes
_5_ Loran-C
_6_ Display color
_7_ Factory settings
When selecting a sub-menu in the
SETUP menu, the display will
always appear in a pop-up window.
Which means that it will not take the
place of another display, and it will
not mess up the pre-set displays on
the screen.
And once you have confirmed the
changes, or just want to exit the
display, the display will disappear
from the screen, as you have no
further use for it.
2.5 Choice of symbols
Waypoints and other points appearing on the screen can be marked by
one of 18 symbols + 8 EVENT marks in small or large symbols.
Waypoint
Red buoy
Green buoy
Wreck
Danger
Beacon
Fish
Platform
Rock awash
Harbour
Marker
North
South
East
West
Starboard
Port
MOB
EVENT 4
(1 of 8 types in
diamond shape)
